Product Information
Haws 3610F ADA Outdoor Vandal-Resistant Stainless Steel Filtered Bottle Filler, Non-Refrigerated, Silver
Model 3610F Description
The Haws 3610F heavy-duty outdoor ADA filtered pedestal bottle filler can be configured in multiple variations before or after installation. This model is standard with a single bottle filler, and the option of adding/changing a drinking fountain, bottle filler, dog bowl and/or hose bib at any time. It incorporates the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve. Equipped with vandal resistant components for long lasting durability.
- Only stainless steel valve body that is machined out of solid bar stock
- 3000 gallon carbon block filter with mounting bracket reduces chlorine (taste and odor) and lead, and removes 99.99% of cysts
- Vandal resistant components include the bottle filler nozzle, button, and access plates
- Heavy-duty fabricated stainless steel with matte silver powder-coated finish
- Modular design allows options and accessories to be added or removed at any time
- Large-opening bottle filler with quick-fill 1 gpm flow rate
- Easy maintenance with front access to valve adjustment and cartridge replacement
- 100% lead-free waterways
Custom Colors Are Available With This Model
- Note: Custom Color lead time is 8 to 10 weeks
Available Options:
- Pet Fountain: Model 3670, dog bowl attachment for 3600 series pedestal fountains.
- Hose Bib: Model 3660, lockable hose bib attachment for 3600 series pedestal fountains.
- Fountain Arm: Model 3671 pedestal arm for adding the option of a bottle filler or fountain attachment.
- Fountain Attachment: Model 3680, drinking fountain bowl attachment.
- Fountain Attachment: Model 3690, bottle filler attachment.
- Nozzle For Bottle Filler: The Haws VRKNOZ1 is a package of ten replacement nozzles for the Haws 3600 series bottle filler. Not for freeze resistant models.
- Installation Aid: Model MTG.3600, mounting plate for 3600 series pedestals.
Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act, and complies with Prop 65. Certified by CSA to NSF/ANSI 61, section 9 and NSF/ANSI 372; and was evaluated to be compliant to US and Canada Plumbing Codes including Uniform Plumbing Code (UPC), International Plumbing Code (IPC) and National Plumbing Code of Canada (NPC).
Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm.
