Sloan DRS120-UNFIL-REF-SS DropSpot™ On-wall Bottle Filler with Bi-Level Cooler
Sloan's DropSpot™ On-wall Bottle Filler with Bi-level Cooler is uniquely designed with style to promote sustainable drinking practices. It is available in both stainless and black finishes. With its touch-free sensor operated bottle filler backed by Sloan's cutting edge sensor technology, this unit provides a hygienic bottle filling experience. ADA compliant when installed properly. Up to 1.2 gpm fill rate for quick fill. Soft ambient white light indicates filter status, a backlit LED light illuminates bottle filling area when sensor is activated. Bottle counter display indicates the number of 16 oz plastic bottles saved as well as the ounces of water dispensed for water consumption tracking. Rough-in matches other manufacturers' for easy replacement. Versatile mounting style allows for left-high or right-high installation. Patent pending push bar is designed to be activated with any touch point to provide easy access for cartridge replacement. Anti-microbial push bar and bubbler for hygienic usage and ease of cleaning. Drop-down door assembly provides easy access to filter, making maintenance and filter change a no-sweat experience.
Bottle Filler:
- Touch-free sensor operated bottle filler with 20 second max run time
- ADA compliant when installed properly
- Up to 1.2 gpm fill rate for quick fill
- Laminar flow water supply
- Soft ambient white light to indicate filter status
- Backlit LED light that illuminates bottle filling area when sensor is activated
- Bottle Counter Display indicates the number of 16 oz plastic bottles saved as well as the ounces of water dispensed for water consumption tracking
Electric Water Cooler:
- ADA compliant when installed properly
- Rough-in matches other manufacturers' for easy replacement
- Antimicrobial bubbler, push bar, and other components
- Drop-down door assembly provides easy access to filter
- Patent pending push bar designed to be activated at any touch point and to provide easy access for cartridge replacement
- Chilling capacity of 8.0 gph of 50F drinking water, based on 80F inlet water and 90F ambient
- Versatile mounting style allows for left-high or right-high installation
Sloan 33820003-DRS120-UNFIL-REF-SS Spec Sheet & Other Downloadable Resources
Sloan DRS120-UNFIL-REF-SS DropSpot™ On-wall Bottle Filler with Bi-Level Cooler
Sloan's DropSpot™ On-wall Bottle Filler with Bi-level Cooler is uniquely designed with style to promote sustainable drinking practices. It is available in both stainless and black finishes. With its touch-free sensor operated bottle filler backed by Sloan's cutting edge sensor technology, this unit provides a hygienic bottle filling experience. ADA compliant when installed properly. Up to 1.2 gpm fill rate for quick fill. Soft ambient white light indicates filter status, a backlit LED light illuminates bottle filling area when sensor is activated. Bottle counter display indicates the number of 16 oz plastic bottles saved as well as the ounces of water dispensed for water consumption tracking. Rough-in matches other manufacturers' for easy replacement. Versatile mounting style allows for left-high or right-high installation. Patent pending push bar is designed to be activated with any touch point to provide easy access for cartridge replacement. Anti-microbial push bar and bubbler for hygienic usage and ease of cleaning. Drop-down door assembly provides easy access to filter, making maintenance and filter change a no-sweat experience.
Bottle Filler:
- Touch-free sensor operated bottle filler with 20 second max run time
- ADA compliant when installed properly
- Up to 1.2 gpm fill rate for quick fill
- Laminar flow water supply
- Soft ambient white light to indicate filter status
- Backlit LED light that illuminates bottle filling area when sensor is activated
- Bottle Counter Display indicates the number of 16 oz plastic bottles saved as well as the ounces of water dispensed for water consumption tracking
Electric Water Cooler:
- ADA compliant when installed properly
- Rough-in matches other manufacturers' for easy replacement
- Antimicrobial bubbler, push bar, and other components
- Drop-down door assembly provides easy access to filter
- Patent pending push bar designed to be activated at any touch point and to provide easy access for cartridge replacement
- Chilling capacity of 8.0 gph of 50F drinking water, based on 80F inlet water and 90F ambient
- Versatile mounting style allows for left-high or right-high installation
